YK-FQL

Float Level Transmitter

The FQL series float level transmitter (Magnetostrictive level meter) consists of a measuring tube, float, reed switches, and other key components. Multiple reed switches are installed inside the sensor. As the magnet-equipped float moves up and down with the liquid level, it activates reed switches at different positions, causing changes in the output resistance and generating a level signal.It is widely used in industries such as oil refining, chemical processing, paper making, food production, and wastewater treatment. It is suitable for open or closed tanks, as well as underground tanks, enabling level display, alarm, and control in control rooms. The measured media can include water, oil, acids, alkalis, and industrial wastewater, whether conductive or non-conductive.

Buy

technology parameter

Structure Type	Integral type	Connection Method	Flanged insertion type, Threaded insertion type
Housing Material	SUS304, SUS316L, Aluminum Alloy	Flange Material	PTFE, SUS304, SUS316L
Probe Material	SUS304, SUS316L, PTFE	Ambient Temperature	-25 ～ 60℃
Process Temperature	-20～ 100℃	Applicable Pressure	<3.0 MPa (can be agreed upon)
Accuracy	±0.5mm	Electrical Connection	M20×1.5 (can be agreed upon)
Output Method	4～20mA, Switching signal	Ingress Protection Rating	IP65, IP66, IP67
Certification	Intrinsically safe, Flameproof	Power Supply Voltage	220VAC, 24VDC

Selection

Measurement Task
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Discrete signal; C:No Output;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; J:DN125; K:DN150; L:DN200; M:G1/2 thread; S:1/2 NPT thread; T:G1 thread; Y:G1½ thread; Z:G1¼ thread; X:Other;
Corrosive Service

A:Yes; B:No;
Insertion Length

A:0-100mm; B:0-200mm; C:0-300mm; D:0-400mm; E:0-500mm; F:0-600mm; G:0-700mm; H:0-800mm; I:0-900mm; J:0-1000mm; K:0-1200mm; L:0-1500mm; M:0-2000mm; N:0-3000mm; O:0-4000mm; P:0-5000mm;
Explosion-Proof Rating

A:Standard; B:EX Explosion-proof; C:EX Intrinsically Safe;
