YK-A6011

Pressure Transmitter

YK-A6011 series pressure transmitter adopts internationally advanced pressure sensing technology, combined with low-power amplification circuitry and temperature compensation technology, to convert measured pressure into standard current or voltage signals. The product offers reliable performance and flexible structural configurations, and is widely used in process control and pressure measurement across industries such as petroleum, chemical, metallurgy, power, light industry, textile, building materials, hydrology and geology, food, pharmaceuticals, and environmental controlThe aluminum alloy housing has an IP65 ingress protection rating, suitable for harsh or outdoor environments. Multiple output signal options are available. Zero and span can be field-adjusted. It can be equipped with 0–100% linear analog gauges, LCD or LED digital displays for on-site pressure indication. Overpressure and anti-interference protection are provided. The intrinsically safe explosion-proof version complies with Ex ib II CT6 requirements.

Buy

technology parameter

Structure Type	Integral type	Connection Method	Threaded, Bracket
Housing Material	SCS14A, Cast aluminum alloy	Connector Material	SCM435, SUS630, SUH660
Diaphragm Material	316L, Hastelloy C-276, Hastelloy C	Ambient Temperature	-30 ～ 70℃
Process Temperature	-20 ～ 100℃	Applicable Pressure	-0.1～14 MPa (can be agreed upon)
Accuracy	±0.1/±0.2%/±0.075%	Electrical Connection	M20×1.5 (can be agreed upon)
Output Method	4～20mA, HART protocol, RS485,	Ingress Protection Rating	IP65, IP66
Certification	Intrinsically safe, Flameproof	Power Supply Voltage	24VDC

Selection

Measurement Task
Temperature Range

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Span

A:-10–1kPa; B:0–5kPa; C:0–10kPa; D:0–50kPa; E:0–100kPa; F:0–1.6MPa; G:0–2.5MPa; H:0–3.2MPa; J:0–10MPa; Z:Customized;
Wetted Parts Material

A:316L; B:Hastelloy; C:Tantalum (TAN);
Output Signal

A:4–20mA;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; V:M20×1.5; P:1/2NPT; S:G1/2; Z:Other;
Accuracy Class

A:0.075%F.S; B:0.1%F.S; C:0.25%F.S; D:0.5%F.S;
Explosion-Proof Rating

A:Standard; B:Explosion-proof; C:Intrinsically Safe;
Electrical Conduit Entry Size

A:M20×1.5; B:G1/2 NPT internal thread; C:1/2 NPT internal thread; D:Other;
