YK-YCWF

Wedge Flowmeter

The wedge flowmeter is a specialized flow measurement device used for measuring steam, gas, and liquid flow. The YK-YCWF series wedge flowmeter features a unique structure with no stagnation zones. It offers a robust, clog-free design, excellent wear resistance, and long service life. It is particularly suitable for measuring low-velocity, high-viscosity fluids (Reynolds number as low as 300) and media containing solid particles, such as crude oil, fuel oil, oil slurry, asphalt oil, coal tar, wastewater, iron ore slurry, carbon black solutions, multiphase flows, and solid-laden fluids.

Buy

technology parameter

Wedge Flow Meter

Selection

Measurement Task
Nominal Diameter (DN)

A:DN15; B:DN20; C:DN25; D:DN32; E:DN40; F:DN65; G:DN80; H:DN100; I:DN125; J:DN150; K:DN200; L:DN250; M:DN300; N:DN350; O:DN400; P:DN450; Q:DN500; R:DN600; S:DN700; T:DN800; U:DN900; V:DN1000; W:DN1100; X:DN1200; Y:DN1300; Z:DN1400; DI:Others;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Pulse; C:Switch Signal; D:No Output;
Installation Type

A:Clamp-on; B:Flanged; C:Insertion type; D:Welded-connection;
Explosion-Proof Rating

A:Standard; B:Explosion-proof; C:Intrinsic Safety;
Grounding Ring or Grounding Electrode

A:Yes; B:No;
