YK-RLEA

Split-Type Ultrasonic Level Meter

Ultrasonic level meters operate by measuring the time-of-flight of sound waves: a sensor emits an ultrasonic pulse that travels through air, reflects off the surface of the medium, and returns to the sensor; knowing the speed of sound in air, the round-trip time is used to calculate the distance to the surface, and subtracting this “empty height” from the known tank depth yields the actual liquid or solid level. In split-type designs, the probe (transducer) and transmitter (signal processor) are separated—ideal for high-temperature, corrosive, or remote-monitoring applications—with the probe mounted directly on the tank and the transmitter installed at an accessible location, connected via cable.

Buy

technology parameter

Structure Form	Split Type	Connection Method	Thread Type, Flange Type
Housing Material	ABS	Flange Material	PP, PTFE, SUS304
Probe Material	PP, PTFE	Ambient Temperature	-25 ~ 60℃
Process Temperature	-20 ~ 90℃	Applicable Pressure	0~1.6 MPa (Negotiable)
Accuracy	±0.5mm	Electrical Interface	M20×1.5 (Negotiable)
Output Mode	4~20mA, RS485, Switch Signal	Protection Grade	IP65, IP66, IP67
Certification	Intrinsically Safe, Flameproof	Power Supply Voltage	220VAC, 24VDC

Selection

Measurement Task
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Discrete signal; C:No Output;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; J:DN125; K:DN150; L:DN200; M:G1/2 thread; S:1/2 NPT thread; T:G1 thread; Y:G1½ thread; Z:G1¼ thread; X:Other;
Measuring Range

A:0-1000mm; B:0-5000mm; C:0-10000mm; D:0–15000mm; E:0-20000mm; F:0-30000mm; G:0-40000mm; H:0-50000mm; I:Other;
Corrosive Service

A:Yes; B:No;
Explosion-Proof Rating

A:Standard; B:Explosion-proof; C:Intrinsically Safe;
