Vibrating Rod (Vibrating Probe) Level Switch

YK-TFB

Vibrating Rod (Vibrating Probe) Level Switch

Vibrating rod level switches, a type of tuning-fork level detector, offer superior performance with no false triggering from material buildup or impact, no trapping issues, and higher sensitivity; their single cylindrical probe leverages resonance principle—driven by piezoelectric elements to vibrate continuously, with vibration amplitude sharply decreasing only when fully surrounded by material, triggering a switch output; ideal for point-level detection of solids, liquid-solid interfaces, and sediment in tanks or silos, they feature no moving parts, corrosion resistance, high sensitivity, and easy installation.

Buy

technology parameter

Structure Form	Integral Type	Connection Method	Threaded Type, Flanged Type
Shell Material	SUS304, SUS316	Structure Type	Standard Type, High Temperature Type
Probe Material	316L	Ambient Temperature	-25 ～ 60℃
Process Temperature	-25 ～ 180℃	Applicable Pressure	4.0 MPa（can be agreed upon）
Accuracy	±1mm	Electrical Connection	M20×1.5（can be agreed upon）
Output Signal	Digital (Switch) Output	Protection Rating	IP65, IP66
Certifications	Intrinsic Safety, Explosion-proof	Power Supply Voltage	220VAC, 24VDC

Selection

Measurement Task
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Discrete signal; C:No Output;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; J:DN125; K:DN150; L:DN200; M:G1/2 thread; S:1/2 NPT thread; T:G1 thread; Y:G1½ thread; Z:G1¼ thread; X:Other;
Insertion Length

A:0-100mm; B:0-200mm; C:0-300mm; D:0-400mm; E:0-500mm; F:0-600mm; G:0-700mm; H:0-800mm; I:0-900mm; J:0-1000mm; K:0-1200mm; L:0-1500mm; M:0-2000mm; N:0-3000mm; O:0-4000mm; P:0-5000mm;
Protection Tube Outer Diameter

A:10mm; B:12mm; C:14mm; D:16mm; E:Customized;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; V:M20×1.5; P:1/2NPT; S:G1/2; Z:Other;
Explosion-Proof Rating

A:Standard; B:EX Explosion-proof; C:EX Intrinsically Safe;
