YK-ZXK

Rotary Paddle Level Controller

Rotary paddle (or obstruction-type) level switches contain a small motor inside an enclosure, connected via a magnetic clutch to a shaft fitted with rotating blades; when no material is present, the blades spin freely with the motor, but upon contact with solid material, the paddle stalls, causing the motor to stop and triggering an alarm signal—providing reliable point-level detection for powders, granules, and bulk solids in silos and hoppers.

Buy

technology parameter

Structure Form	Integrated, Cable Type	Connection Method	Screw Type, Flange Type
Shell Material	SUS304, Aluminum Alloy	Probe Material	Stainless Steel
Impeller Speed	5～6 rpm	Ambient Temperature	-25 ～ 80℃
Process Temperature	-40 ～ 300℃	Applicable Pressure	1.0 MPa, 1.6 MPa, 4.0 MPa (can be agreed upon)
Sensitivity	Five-level adjustable mechanism	Electrical Interface	M20×1.5 (can be agreed upon)
Output Method	Digital (Switch) Output	Protection Class	IP65, IP66
Certification	Intrinsic Safety, Flameproof	Power Voltage	220VAC, 24VDC

Selection

Measurement Task
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Discrete signal; C:No Output;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Insertion Length

A:0-100mm; B:0-200mm; C:0-300mm; D:0-400mm; E:0-500mm; F:0-600mm; G:0-700mm; H:0-800mm; I:0-900mm; J:0-1000mm; K:0-1200mm; L:0-1500mm; M:0-2000mm; N:0-3000mm; O:0-4000mm; P:0-5000mm;
Protection Tube Outer Diameter

A:10mm; B:12mm; C:14mm; D:16mm; E:Customized;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; V:M20×1.5; P:1/2NPT; S:G1/2; Z:Other;
Explosion-Proof Rating

A:Standard; B:EX Explosion-proof; C:EX Intrinsically Safe;
