YK-WRN-T

Explosion-Proof Thermocouple

Explosion-proof thermocouples are widely used in chemical process automation systems where flammable gases or vapors are present; unlike standard thermocouples, they are designed to prevent ignition of hazardous atmospheres by containing any internal sparks or thermal energy. Operating on the thermoelectric (Seebeck) effect—generating a voltage from the temperature difference between two dissimilar metal junctions—they convert process temperature into a safe electrical signal for display, recording, or control, and are extensively deployed in oil & gas, chemical, and metallurgical plants for reliable operation in explosive environments.

Buy

technology parameter

Explosion-Proof Thermocouple

Selection

Measurement Task
Span Range

A:0–100℃; B:0–350℃; D:0–600℃; E:0–1200℃; F:0–1600℃; G:0–2300℃;
Working Pressure

A:0–1.6MPa; B:0–2.5MPa; C:0–3.2MPa; D:0–6.3MPa;
Insertion Length

A:0-100mm; B:0-200mm; C:0-300mm; D:0-400mm; E:0-500mm; F:0-600mm; G:0-700mm; H:0-800mm; I:0-900mm; J:0-1000mm; K:0-1200mm; L:0-1500mm; M:0-2000mm; N:0-3000mm; O:0-4000mm; P:0-5000mm;
Protection Tube Outer Diameter

A:10mm; B:12mm; C:14mm; D:16mm; E:Customized;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; V:M20×1.5; P:1/2NPT; S:G1/2; Z:Other;
Explosion-Proof Rating

A:Standard; B:EX Explosion-proof; C:EX Intrinsically Safe;
Calibration Type (or Index Number)

1:K; 2:N; 3:E; 4:J; 5:T; 6:S; 7:R; 8:B; 9:Other;
Number of RTD Elements

A:Single-element; B:Dual-element;
Output Signal

A:RTD (Resistance Temperature Detector); B:Thermocouple; C:4–20mA; D:0–5V; E:PT100;
