YK-A60-14

Differential Pressure Transmitter

Differential pressure transmitters operate through a diaphragm-sealed sensing element that divides the internal space into two chambers; when process pressures are applied to each chamber, the resulting pressure difference causes the diaphragm to deflect proportionally, and this displacement is converted into a standard output signal; performance is influenced by the sensor’s structural design, chamber configuration, and displacement-to-signal conversion method; these transmitters measure liquids, gases, and steam across a wide range—from 0–0.1 kPa to 0–40 MPa—with a standard 4–20 mA DC output and a power supply requirement of 12–45 V DC (typically 24 V DC), making them indispensable in industrial measurement applications.

Buy

technology parameter

Structure Form	Integral Type	Mounting Method	Threaded, Bracket
Shell Material	SUS304, SUS316, Cast Aluminum Alloy	Fastener Material	SCM435, SUS630, SUH660
Diaphragm Material	316L, Hastelloy B, Hastelloy C, Monel	Ambient Temperature	-30 ～ 70℃
Process Temperature	-20 ～ 100℃	Applicable Pressure	0.14～14 MPa（can be agreed upon）
Accuracy	±0.075	Electrical Connection	M20×1.5（can be agreed upon）
Output Signal	4～20mA, HART Protocol, RS485,	Protection Rating	IP65, IP66, IP67
Certifications	Intrinsic Safety, Explosion-proof	Power Supply Voltage	24VDC

Selection

Measurement Task
Temperature Range

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Span

A:-10–1kPa; B:0–5kPa; C:0–10kPa; D:0–50kPa; E:0–100kPa; F:0–1.6MPa; G:0–2.5MPa; H:0–3.2MPa; J:0–10MPa; Z:Customized;
Wetted Parts Material

A:316L; B:Hastelloy; C:Tantalum (TAN);
Output Signal

A:4–20mA;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; V:M20×1.5; P:1/2NPT; S:G1/2; Z:Other;
Accuracy Class

A:0.075%F.S; B:0.1%F.S; C:0.25%F.S; D:0.5%F.S;
Explosion-Proof Rating

A:Standard; B:Explosion-proof; C:Intrinsically Safe;
Electrical Conduit Entry Size

A:M20×1.5; B:G1/2 NPT internal thread; C:1/2 NPT internal thread; D:Other;
