YK-IEF

Electromagnetic Flow Meter

Electromagnetic flow meters consist of two parts: a sensor and a converter. Based on Faraday’s law of electromagnetic induction, they measure the volumetric flow rate of conductive liquids with conductivity greater than 5 μS/cm, making them inductive instruments for measuring the volumetric flow of conductive media. In addition to general conductive liquids, they can also measure highly corrosive fluids such as strong acids and strong alkalis, as well as uniform liquid-solid two-phase suspensions like slurry, mineral pulp, and paper stock. They are widely used for flow measurement in industries including petroleum, chemical processing, metallurgy, textiles, papermaking, environmental protection, and food production, as well as in municipal management, water conservancy projects, and river dredging.

Buy

technology parameter

Structure Form	Integrated Type, Split Type	Connection Method	Wafer Type, Flange Type, Insert Type
Housing Material	Carbon Steel, SUS304, SUS316	Lining Material	Rubber, PTFE, PFA, F46
Electrode Material	316L, Hastelloy B, Hastelloy C, Tantalum, Titanium, Platinum, Tungsten Carbide	Ambient Temperature	-25 ~ 80℃
Process Temperature	-25 ~ 110℃	Applicable Pressure	1.0 MPa, 1.6 MPa, 4.0 MPa (Negotiable)
Accuracy	±0.5%	Electrical Interface	M20×1.5 (Negotiable)
Output Mode	Pulse Output, 4~20mA, HART Protocol, RS485, Relay	Protection Grade	IP65, IP68
Certification	Intrinsically Safe and Flameproof	Power Supply Voltage	220VAC, 24VDC, Battery

Selection

Measurement Task
Nominal Diameter (DN)

A:DN15; B:DN20; C:DN25; D:DN32; E:DN40; F:DN65; G:DN80; H:DN100; I:DN125; J:DN150; K:DN200; L:DN250; M:DN300; N:DN350; O:DN400; P:DN450; Q:DN500; R:DN600; S:DN700; T:DN800; U:DN900; V:DN1000; W:DN1100; X:DN1200; Y:DN1300; Z:DN1400; DI:Others;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Pulse; C:Switch Signal; D:No Output;
Installation Type

A:Clamp-on; B:Flanged; C:Insertion type; D:Welded-connection;
Converter Type

A:Integral; B:Remote;
Protection Rating (IP Rating)

A:IP65; B:IP66; C:IP67; D:IP68;
Explosion-Proof Rating

A:Standard; B:Explosion-proof; C:Intrinsic Safety;
Grounding Ring or Grounding Electrode

A:Yes; B:No;
