YK-VFF-E

Intelligent Vortex Flow Meter

The intelligent integrated vortex flow meter combines flow, temperature, and pressure sensors into a single unit. Building on all traditional advantages, it employs modern microprocessor technology and a built-in LCD display to directly calculate standardized volumetric or mass flow rates for gases and steam without requiring an external flow computer—i.e., it performs automatic temperature and pressure compensation on-site. The vortex flow transmitter is primarily used for measuring flow of various media (gases, liquids, and steam) in industrial pipelines. It features low pressure loss, wide turndown ratio, high accuracy, and minimal dependence on fluid density, pressure, temperature, or viscosity during actual volumetric flow measurement. With no moving mechanical parts, it offers high reliability and low maintenance. Its meter factor remains stable over time. Insertion-type models can be installed via a pipe tap with a ball valve, enabling installation and maintenance without interrupting flow—ideal for periodic cleaning in dirty media. Equipped with a piezoelectric stress sensor, it operates reliably across a temperature range of –20 °C to +250 °C and provides both analog standard signals and digital pulse outputs, making it easy to integrate with computerized digital systems—an advanced and ideal flow measurement solution.

Buy

technology parameter

Structure Type	Integral type, Separate type	Connection Method	Clamp type, Flange type,
Housing Material	Carbon steel, SUS304, SUS316	Structure Type	Normal pressure type, High pressure type, Submersible type
Electrode Material	316L, Hastelloy B, Hastelloy C	Ambient Temperature	-25 ～ 80℃
Process Temperature	-20 ～ 350℃	Applicable Pressure	1.0 ～4.0MPa, 6.3～42 MPa (can be agreed upon)
Accuracy	±1.0%/1.5%	Electrical Connection	M20×1.5 (can be agreed upon)
Output Method	Pulse output, 4～20mA, HART protocol, RS485	Ingress Protection Rating	IP65, IP66, IP67, IP68
Certification	Intrinsically safe, Flameproof	Power Supply Voltage	24VDC, Battery

Selection

Measurement Task
Nominal Diameter (DN)

A:DN15; B:DN20; C:DN25; D:DN32; E:DN40; F:DN65; G:DN80; H:DN100; I:DN125; J:DN150; K:DN200; L:DN250; M:DN300; N:DN350; O:DN400; P:DN450; Q:DN500; R:DN600; S:DN700; T:DN800; U:DN900; V:DN1000; W:DN1100; X:DN1200; Y:DN1300; Z:DN1400; DI:Others;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Pulse; C:Switch Signal; D:No Output;
Installation Type

A:Clamp-on; B:Flanged; C:Insertion type; D:Welded-connection;
Converter Type

A:Integral; B:Remote;
Protection Rating (IP Rating)

A:IP65; B:IP66; C:IP67; D:IP68;
Explosion-Proof Rating

A:Standard; B:Explosion-proof; C:Intrinsic Safety;
Grounding Ring or Grounding Electrode

A:Yes; B:No;
