YK-LT

Submersible Level Transmitter

Submersible level transmitters measure liquid depth in industries like petrochemicals, metallurgy, and power generation based on hydrostatic pressure principles; they consist of a vented cable, pressure-resistant connector, and probe—typically featuring a stainless-steel housing with a diaphragm and ceramic sensor that converts liquid head pressure into a 4–20 mA standard signal; available in integral or remote configurations with ranges up to 0–30 meters, they are suitable for level monitoring in clean water, sewage, brine, and similar media.

Buy

technology parameter

Structure Form	Submersible, Straight Rod	Connection Method	Flange Type, Threaded Type
Housing Material	Cast Aluminum	Lined Fluorine	PTFE (Customizable)
Display Type	3 1/2 Digit LED	Ambient Temperature	-20～60℃
Process Temperature	-20～100℃	Applicable Pressure	0-2.5MPa
Precision	0.25%	Electrical Interface	M20×1.5 (can be agreed upon)
Output Method	4～20mA, HART Protocol, RS485	Protection Rating	IP65, IP66
Certification	Intrinsic Safety and Flameproof	Power Supply Voltage	24VDC

Selection

Measurement Task
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Discrete signal; C:No Output;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; J:DN125; K:DN150; L:DN200; M:G1/2 thread; S:1/2 NPT thread; T:G1 thread; Y:G1½ thread; Z:G1¼ thread; X:Other;
Measuring Range

A:0-1000mm; B:0-5000mm; C:0-10000mm; D:0–15000mm; E:0-20000mm; F:0-30000mm; G:0-40000mm; H:0-50000mm; I:Other;
Corrosive Service

A:Yes; B:No;
