YK-RLEA

Integral Ultrasonic Level Meter

The working principle of ultrasonic level measurement relies on the constant speed of sound in air: the meter emits a sound wave and starts timing; upon receiving the echo reflected from the material surface, it stops timing. Since the measured time corresponds to the round-trip travel, the actual distance is half the total path. Given a fixed tank or pool height, the level is calculated as the total height minus this measured distance, enabling non-contact, continuous level monitoring for both liquids and solids.

Buy

technology parameter

Structure Form	Integrated Type	Connection Method	Thread Type, Flange Type
Housing Material	ABS	Flange Material	PTFE, PP, SUS304
Probe Material	PP, PTFE	Ambient Temperature	-25 ~ 60℃
Process Temperature	-25 ~ 90℃	Applicable Pressure	0~1.6 MPa (Negotiable)
Accuracy	±0.5mm	Electrical Interface	M20×1.5 (Negotiable)
Output Mode	4~20mA, RS485, Switch Signal	Protection Grade	IP65, IP66, IP67
Certification	Intrinsically Safe, Flameproof	Power Supply Voltage	220VAC, 24VDC

Selection

Measurement Task
Operating Temperature

A:≤80℃; B:≤120℃; C:≤200℃; D:≤300℃; E:≤400℃;
Pressure Rating

A:0–1.6MPa; B:0–2.5MPa; C:0–4.0MPa; D:0–6.3MPa; E:0–10MPa;
Output Signal

A:4–20mA; B:Discrete signal; C:No Output;
Power Supply

A:24VDC; B:220VAC; C:Non-powered;
Process Connection Size

A:DN20; B:DN25; C:DN32; D:DN40; E:DN50; F:DN65; G:DN80; H:DN100; J:DN125; K:DN150; L:DN200; M:G1/2 thread; S:1/2 NPT thread; T:G1 thread; Y:G1½ thread; Z:G1¼ thread; X:Other;
Measuring Range

A:0-1000mm; B:0-5000mm; C:0-10000mm; D:0–15000mm; E:0-20000mm; F:0-30000mm; G:0-40000mm; H:0-50000mm; I:Other;
Corrosive Service

A:Yes; B:No;
